EMCA Banding Backshells, Straight

EMCA Straight Band Terminating Backshells define the standard for highly reliable, environment resisting, electrically passive components.

Applications:

  • Termination of screened and braided cables.
  • For high level shielding effectiveness.
  • Environmental sealing performance acc. to VG 95319-1011.

Advantage:

  • Screen termination using M85049/128 Bands
  • Sealing and strain relief of backshell by heat shrink boot
  • Overall Screen, Tool-free, Reworkable

Many plating options

  • High corrosion resistance and electrical continuity properties.



Image result for emca gmbh logo



EMCA Datasheets – DOWNLOAD
  • A37-866-XXXX to suit MIL-DTL-38999 Series III & IV
  • A87-572-XXXX to suit MIL-DTL-26482 Series II, MIL-DTL-83723 Series III & MIL-DTL-5015H (MS34_)


Additional information

Angle

Straight: A37-866-

Entry Size

03: 0.19 [4.70mm], 04: 0.25 [6.35mm], 05: 0.31 [7.92mm], 06: 0.37 [9.52mm], 07: 0.44 [11.10mm], 08: 0.50 [12.70mm], 09: 0.56 [14.20mm], 10: 0.62 [15.80mm], 11: 0.69 [17.40mm], 12: 0.75 [19.00mm], 13: 0.81 [20.60mm], 14: 0.87 [22.20mm], 15: 0.94 [23.80mm], 16: 1.00 [25.40mm], 17: 1.06 [27.00mm], 18: 1.13 [28.60mm], 19: 1.19 [30.20mm], 20: 0.86 [21.80mm], 21: 1.31 [33.30mm], 22: 1.38 [35.00mm], 23: 1.44 [36.50mm], 24: 1.50 [38.10mm]

Material & Finish

1: Stainless Steel, 2: Zinc Nickel Black, 5: Electroless Nickel, 6: Cadmium Olive Drab, 9: Marine Bronze, J: Black Selective Plated (RoHS), U: Olive Drab Selective Plated (RoHS)

Shell Size

1) 09 (A), 2) 11 (B), 3) 13 (C), 4) 15 (D), 5) 17 (E), 6) 19 (F), 7) 21 (G), 8) 23 (H), 9) 25 (J)
