Description
A USB Type-A feedthrough receptacle in a jam-nut shell — a straight pass-through with a USB-A socket on both faces, for panels that simply need a port brought through.
- Shell derived from D38999
Key specifications
| Voltage Rating (V_BUS) | 30 V |
|---|---|
| Current Rating (V_BUS) | 1,8 A |
| Temperature | -40 °C to +85 °C |
| Mating cycles | >500 |
Materials
| USB A shell | Nickel plated |
|---|---|
| Housing | See option material |
| PCB | FR4, UL94V-0 |
Material & plating options
| Code | Technical design | RoHS / REACH | Electrically conductive | Salt spray (MIL) | Salt spray (VG) |
|---|---|---|---|---|---|
| V | Tin-Zinc grey Base material: Al-alloy; Tin-Zinc over electroless Nickel |
Yes | Yes | 500 hrs | 5 day cyclic |
| 5 | Electroless Nickel Base material: Al-alloy |
Yes | Yes | 48 hrs | n.a. |
| 2 | Zinc-Nickel black Coupling ring: Al-alloy, black anodized; shell: Zinc-Nickel black chromate over electroless Nickel |
Yes | Yes | 500 hrs | n.a. |
| 6 | Cadmium olive drab Coupling ring: Al-alloy, olive drab anodized; shell: Al-alloy cadmium plated olive drab over electroless Nickel |
No | Yes | 500 hrs | 5 day cyclic |
| 9 | Marine Bronze CuAl10Ni5Fe4 (CW307G), shotblast, nonreflective |
Yes | Yes | n.a. | n.a. |
| 1 | Stainless Steel Passivated |
Yes | Yes | n.a. | n.a. |
How to order
A full part number is built up from:
- Basic part number
- Shell size
- Material & plating code
- Keyway polarization
- USB A orientation
Order example: X2-9853-15-5 N 0
- USB A FEEDTHROUGH – JAM NUT
- SIZE 15
- ELECTROLESS NICKEL
- KEYWAY = N (STANDARD)
- USB A ORIENTATIONS = 0° (See drawing)
Dimensioned drawing & full datasheet
Open the X2-9853 datasheet — page 36 of the EMCA Harsh Environment Data Connectivity Solutions catalogue, with full dimensions in mm (inch).
